ARMSTRONG'S 1100S04-54-HD is a 180 degree heavy duty glass to glass hydraulic hinge.

The 1100S04-54-HD has rectangular corners edges for a sleek appearance. The 1100S04-54-HD Series Heavy Duty Hinges accommodate 5/16" (8 mm) to 3/28" (10 mm) thick tempered safety glass. Soft-closing function at 0-80 degree, and fixed position at 85~90 degree. 1100S04-54-HD Series Hydraulic Hinges embed the hydraulic plunger enable the door to close smoothly and quietly, which enhance the life time . 1100S04-54-HD also can adjust closing angle, which makes installation easier.

• Rectangular corners and edges
• Designed For 5/16"-1/2" (8 mm to 12 mm) Tempered Glass
• Soft-closing within 0~80 degree
• Fixed position at 85~90 degree
• Commonly used in Residential Bath and Commercial Hotel Applications
• Many Popular Finishes to Select From
• Material: 304 Stainless Steel

• MAXIMUM DOOR CAPACITY	3/8" (10 mm) GLASS Approx. 5 lb./ft²	1/2" (12 mm) GLASS Approx. 6.4 lb./ft²
  	DOOR WEIGHT	DOOR WIDTH
  Using 2 Hinges	99 LBS (45 kg)	31.5" (800 mm)
  Using 3 Hinges	132 LBS (60 kg)	36" (914 mm)




• 304 Stainless steel
• Over 50,000 times open-close cycles
• Available in many different colors
• Soft-closing
• Angle adjustable

• Commonly used in Residential Bath and Commercial Hotel Applications
